11
MOTOR INTEGRATION
• Fully integrated and secured by 6 bolts (3 each side)
• Quick motor removal (a trained, well-organized technician
needs 10 -15 minutes)
BATTERY INTEGRATION
• Main battery is fully integrated into downtube
• Main battery can only be removed after removing motor
• Chargeable internally through frame charge port
HEADSET
• All fully integrated and custom for internal cable routing
• All bearings and other headset parts are available on
the Service Website
WHEEL SPACING / REAR AXLE
• 135mm spacing
• Drop out for full axle of internal gear hub
TIRE COMPATIBILITY
• All MY22 Turbo Como SL models come stock with
650Bx2.3 tires
tire and fender
• Actual tire compatibility depends on tire tread
THE CHASSIS
FRAME MEASUREMENTS & COMPATIBILITY
BRAKE MOUNT / ROTORS
• Flat mount
• Center lock hubs
• Stock rotor size: 160 mm
• Max. rotor size: 160 mm
DEFAULT CHAINRING/SPROCKET SPECIFICATIONS
• 46t chainring + 22t sprocket (5.0 models)
• Used sprocket style: Gates CDX SUREFIT 3-LOBE
• 40t chainring + 30t sprocket (4.0 models)
THE CHASSIS
FORK MEASUREMENTS & COMPATIBILITY
GENERAL
• Identical forks with different steerer lengths per frame size
• Full aluminum, non-tapered (1 1/8” throughout)
• Through-hole in fork crown to mount fender and, potentially,
the front light
• Eyelets for low-rider rack
AXLE TYPE (ALL FORKS)
• 110mm (Boost)
• 12mm thru axle
BRAKE MOUNT / ROTORS
• Flat mount
• Center lock hubs
• Stock rotor size: 160mm
• Max. rotor size: 160mm
