| Functionality | 33

Start pixel index Parameter width [bit] Parameter Description

28 32 Timer 2 Value in units of clock

cycles

32 32 Timer 3 Value in units of clock

cycles

36 24 Integration Time in units of clock

cycles

40 24 Reserved

44 32 Reserved

48 12 Image Average Value("raw" data

without considering gain settings)

52 12 Horizontal start position of ROI

(OffsetX)

56 12 Image Width

60 12 Vertical start position of ROI

(OffsetY). In MROI-mode this

parameter is the start position of the

first ROI.

64 12 Image Height

68 2 Digital Gain

72 12 Digital Offset

76 16 FineGain. This is a fixed-point value

in the format: 4 digits integer value,

12 digits fractional value.

80 1 Line Input Level

84 16 Camera Type Code

88 32 Camera Serial Number

92 32 Custom value 0: value of register

StatusLineCustomValue0 that can be

set by the user

96 32 Custom value 1: value of register

StatusLineCustomValue1 that can be

set by the user

Test Images

Test images are generated in the camera FPGA, independent of the image sensor. They can be used to check the

transmission path from the camera to the frame grabber. Independent from the configured grey level resolution, every

possible grey level appears the same number of times in a test image. Therefore, the histogram of the received image

must be flat.

Note: A test image is a useful tool to find data transmission errors that are caused most often by a defective

cable between camera and frame grabber.

Specim FX17 User Manual
