| Technical Information | 43
Characteristics NIR
# Spatial pixels 640
Spectral binning options 1x 2x 4x
# Spectral pixels covering the specified range 230 115 57
Spectral sampling/pixel 3.5 nm 7 nm 14 nm
Spectral Resolution FWHM 8 nm (mean)
SNR @ max. signal 1000:1
Frame rate (fps), full range (230 bands) max.
1
FX17 = 670 FPS
FX17e = 527 FPS
Frame rate (fps), MROI examples.
4 adjacent bands 15000 FPS
50 bands ~ 5000 FPS
Integration time Adjustable, within frame time
Data interface 12 bits
Sensor Cooling TEC
Shutter Electromechanical shutter for dark background
registration, user-controllable by software
For more information on maximum frame rates, refer to Technical Note: Maximum frame rates in FX10/FX10e and
FX17/FX17e.
Mechanical Specifications
This section describes the mechanical specifications of the Specim FX17 / FX17e.
Table 9: Mechanical Specification
Characteristics Value
Housing Painted aluminium case
Size (L x W x H) 150 x 75 x 85 mm
Weight 1.3 kg
1
FX17e performance depends on the network utilization
All rights reserved - Specim, Spectral Imaging Oy Ltd.
