Speco VIP2P1 - 4.4 Product Specification

4.4 Product Specification
Image sensor 1/2.8” Progressive scan RGB CMOS
Active Array 1920(H) x 1080(V)
Lens Fixed 3.7mm Lens, F1.8
Angle of View
89.0°(H) x 46.0(V)
Min. illumination 1.6 Lux
C
A
M
E
R
A
Shutter Speed 1/20,000 ~ 1/30 (Slow shutter 1/15, 1/8 and 1/4)
Video Compression
-. Motion JPEG
-. MPEG-4 Part2
-. H.264 (MPEG-4 Part 10)
-. Profiles: H.264 HP, MP, and BP, MPEG-4 SP
Video Streaming
Simultaneously H.264(or MPEG-4) and MJPEG
Controllable Frame Rate and Bandwidth VBR/CBR H.264 and
MPEG-4
Video Resolutions 1920x1080 ~ 320x240
Frame Rate 30fps @ 1920x1080, 30fps @ 1280x720
Protocol
TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, QoS, FTP, uPnP, RTP,
RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour
Security
Multi-user authority, HTTPS, IP Filtering, Privacy Zone
Wireless: WEP, WPA-PSK, WPA2
WPS: Software WPS setup (VIP2P1N model only)
Max. Connection 10
API Programming Interface
API Supported,
Open Platform Compatible: ONVIF
Alarm IN / OUT
IN : 1 Ext input, Motion Detection, Manual Trigger
OUT : 1 Ext output
Alarm Events
-. File upload via FTP and HTTP
-. Notification via E-mail, HTTP and TCP
Video Buffering Pre and Post Alarm
Motion Detection Yes, max. 8 programmable zone
Network Time Synchronization Yes
SD Recording Yes, Continuous/Event
Software Reset Yes
Factory Reset Yes, Button/Web browser
Auto Recovery Yes
Installation Tool SpecoManager, Speco VMS
Upgrade Web browser, SpecoManager, Speco VMS
N
E
T
W
O
R
K
Video out (CVBS) Yes, with AD Key (not supplied)
Ethernet
RJ-45 10BASE-T/100BASE-TX
Built-in IEEE 802.11b/g/n wireless LAN
Operating Temperature -10°C ~ 40°C
Operation Humidity 0~80% (non-condensing)
Power Consumption
DC 12V 375mA, 4.5W / PoE 93mA, 4.5W
Power over Ethernet IEEE 802.3af Class0
Dimensions (H x D)
2.15” x 4.53”
G
E
N
E
R
A
L
Unit Weight 8.03 oz
70
