Speco VIP2P1 - 1.3 Layout

1.3 Layout
NO Name Description
1 Alarm Cable
Yellow : Alarm input, Black : GND, Blue : Alarm output
2 Power Cable
Cable for Power source (DC 12V)
3 Ethernet Cable
Cable for Ethernet (POE)
 Camera Dimension
See the diagrams below for the exact dimension
Dimensions Unit: inch
9
