Spectra Precision Focus 8 Series Total Station User Guide 15
Introduction 1
Figure 1.2 Focus 8 series total station – Face-2
Horizontal axis
indication mark
Objective
Battery box
LASER LIGHT IS
EMITTED FROM
THIS PART.
Data output /
external power
input connector
Input voltage
shall be
Circular level
Battery box
release knob
Leveling screw
Tribrach
Laser class label
Optical or
optional laser
plummet
(This picture
shows
the optical
plummet.)
4.5-5.2 V DC
Figure shows Focus 8 2"
Laser aperture
Laser class label
Lumi guides
label
