Spectra Precision Focus 8 Series User Manual

2 Preparation
24 Spectra Precision Focus 8 Series Total Station User Guide
Detaching and re-attaching the battery pack
Detaching the battery pack
CAUTION – Avoid touching the contacts on the battery pack.
1. If the instrument is turned on, press  to turn it off.
2. Turn the battery box release knob counterclockwise, open the battery box cover
and remove the battery pack from the battery box.
Inserting the battery pack
Before inserting the battery pack, clear any dust or other foreign particles from the
battery contacts.
1. Turn the battery box release knob counterclockwise and open the battery box
cover.
2. Put the battery pack into the battery box. Insert the battery pack with the
connectors bottom first, facing inside.
3. Close the battery box cover and turn the knob clockwise until the secure click
sound is heard.
CAUTION – If the battery box cover is not closed, this could adversely affect the
watertightness of the instrument.
