1 Introduction
14 Spectra Precision Focus 8 Series Total Station User Guide
Parts of the instrument
Figure 1.1 and Figure 1.2 show the main parts of the Focus 8 series instrument.
Figure 1.1 Focus 8 series total station – Face-1
Telescope
Telescope
Diopter ring
Face-1 display /
Horizontal axis
Vertical tangent
Battery box
Upper plate
screw
tangent screw
focusing ring
eyepiece
keyboard
Carrying handle
Optical sight
(Finder)
Reticle plate cover
Label for CFR
Tribrach clamp knob
Battery box
release knob
indication mark
Label for FCC
Figure shows Focus 8 2"
USB ports
Stylus pen
(For details,
refer to p.x.)
(For details,
refer to p.x.)
