Figure 6.2 Prism reflector side
Note – Focus 8 series must be used with the Tribrach W30 or W30b.
Mini prism C
Mini prism
holder
Mini prism
adapter
Telescopic
prism pole
Coaxial target plate
for single prism
Tiltable single
prism holder
Prism adapter
Tripod for telescopic prism pole
Standard round
single prism C
Target pole
Triple prism
holder
Tribrach adapter 15
Nikon tripod
Tribrach W30/W30b
Height adjustment
adapter is not used.
