Spectra Precision QuickMark Layout QML800 User Manual

Control Lines
Create control lines in the job file – in the same location as control lines are on the floor.
A) Input Offset Distance
C) Select which Side to Offset
B) Tap Entity to offset (often column line)
12
Set Up QML800 at Job Site Floor
Create Control Lines
D) Create Control Line
