Spectra Precision QuickMark Layout QML800 User Manual

Specifications and WiFi
32
System
Feature
QML800 QML800G
Size
laser instrument
packaged case
267 x 165 x 165mm( 10.5 x 6.5 x 6.5 in)
700 x 455 x 254mm ( 28 x 18 x 10 in)
267 x 165 x 165mm( 10.5 x 6.5 x 6.5 in)
540 x 404 x 305mm ( 22 x 16.5 x 12 in)
Weight
laser instrument
packaged case
2.7 kg ( 6 LBS)
10.5 kg (23 LBS)
2.7 kg ( 6 LBS)
13.6 kg (30 LBS)
Accuracy
3mm (1/8") typical (see chart)
3mm (1/8") typical (see chart)
Self Leveling range
4 +/
-1 deg from true level.
4 +/
-1 deg from true level.
Working range
- t
ypical work area
- la
ser visible distance
- 30m x 30m (130ft x 130ft)
- 22m
(700ft)
- 40m
x 40m (130ft x 130ft)
- 30m
(100ft)
Environmental
- IP
- O
perating Temperature
- S
torage temp
IP54
-
10C – 45C (14F to 113F)
-
20C - 60C (-4F to 140F)
IP54
-
10C – 45C (14F to 113F)
-
20C - 60C (-4F to 140F)
Battery
type and rating
operating time
charge time
Lithium ion 2 x 5200
mAh, 3.7 V
16 hrs
12
hrs
Lithiun
ion 2 x 5200 mAh, 3.7 V
8 - 10 hrs
12
hrs
Charger
Input: 100
- 240V AC 500mA
Output: 5V DC 2A
Input: 100
- 240V AC 500mA
Output: 5V DC 2A
Laser Class
Laser class II
Laser class II
Laser type
642nm red
522nm green
Tripod
height
attachment
0.48m -0.84m (19 in to 33 in)
5.8 x 11
0.48m -0.84m (19 in to 33 in)
5.8 x 11
Controller
Model
Google Nexus 7
Shield
Manufacturer
Asus
Nvidia
Size (diagonal active screen)
7 inch (175mm)
8 inch (200mm)
Weight (in protective case)
0.6 LB (0.3Kg)
0.6 LB (0.3Kg)
Wireless
Protocal
Frequency
Range (typical)
IEEE 802.11b/g/n
2.4
- 2.497 GHZ
45m (150 ft)
IEEE 802.11b/g/n
2.4
- 2.497 GHZ
45m (150 ft)
Shipping
System size
30 x 21 x 11 in / 760 x 530 x 275 mm
23 x 18 x 17 in / 580 x 455 x 430 mm
System weight
36 LBS / 16.3 kg
41 LBS / 18.5 kg
Clutter Buster size
48 x 14 x 9 in / 122
-0 x 355 x 228 mm
Clutter Buster weight
13 LBS / 6 kg
