Specifications
This Chapter includes the following topics:
3.1 General Specifications 10
3.2 PCIe Power 10
3.3 IRIG AM Input 10
3.4 IRIG DCLS Input 10
3.5 IRIG AM Output 10
3.6 IRIG DCLS Output 11
3.7 10-MHz Output 11
3.8 External 1PPS Input 12
3.9 1PPS Output 12
3.10 GPIO Inputs 13
3.11 GPIO Outputs 13
3.12 GNSS Receiver Specifications 13
3.12.1 RF Connector, Internal GNSS Receiver 14
3.12.2 Electrical Characteristics, GNSS RF Signal14
3.13 External GNSS Receiver 14
3.13.1 Connector 14
3.13.2 Electrical Characteristics, Board to
Receiver Transmission 14
3.13.3 Electrical Characteristics, Receiver to
Board Transmission 14
3.13.4 Electrical Characteristics, Receiver Power 15
3.14 Environmental Specifications 15
CHAPTER 3 • Instruction Manual XYZ
9
