7.1 Options
A TCXO oscillator is standard. An available OCXO oscillator may be purchased as an option.
7.2 Accessories
7.2.1 Adapter Cable, Timing Interface
The included 6"-adapter cable is used to connect the breakout cable to the 25-pin timing inter
face connector.
Figure 7-1: Adapter cable
END "A" END "B"
PIN-1 PIN-1
PIN-2 PIN-2
PIN-3 PIN-3
PIN-4 PIN-4
PIN-5 PIN-5
PIN-6 PIN-6
PIN-7 PIN-7
