Spectracom TSync-PCIe - Table 4-2: Adapter Pinout, Ext. GNSS Receiver

Signal END "A" END "B"
1PPS + 9 6
1PPS – 14 3
UP + 12 8
UP – 13 5
DOWN + 10 4
DOWN – 11 7
SHIELD SHELL SHELL
Table 4-2:
Adapter pinout, ext. GNSS receiver
20
CHAPTER 4 • Instruction Manual XYZ Rev. R
4.2 External GNSS Connector Pinout
