Spectracom TSync-PCIe - GNSS Cables; Table 7-3: Pinout, Basic Breakout Cable

Pin Signal Pin Signal
P4—IRIG AM Output (BNC Female)
1 IRIG AM Output BS Ground
P5—1PPS Input (BNC Female)
1 External 1PPS Input BS Ground
P6—1PPS Output (BNC Female)
1 1PPS Output BS Ground
Table 7-3:
Pinout, basic breakout cable (unspecified poins are not connected in the table)
7.2.4 GNSS Cables
Contact Spectracom for more information on GNSS cable length options.
If your TSync-PCIe board is configured to be operated with an external GNSS receiver, it will
have shipped with a GNSS receiver adapter cable. Additional information see under "External
GNSS Connector Pinout" on page19.
7.2 Accessories
