SPEKTRUM DX4S • TRANSMITTER INSTRUCTION MANUAL
EN
IDENTIFYING CONTROLS AND SWITCHES
Function
A
Switch A
B
Switch B
C
Switch C
D
Switch D
E
Switch E
F
Switch F
G
Roller Selector
H
Memory Card Port
(under rubber grip)
Function
I
Rubber Grip
J
Power Switch
K
Power LED
L
Battery Cover
M
Throttle Trigger
N
Steering Wheel
O
Antenna
LCD Screen
O
N
M
K
J
I
H
G
F
E
D
C
B
A
L
INSTALLING BATTERIES
CAUTION: NEVER remove the transmitter batteries while the model is powered on. Loss of model control, damage or injury
may occur.
C
A
B
Press the power switch (J)
to power ON the transmit-
ter. The Power LED (K) will
come on, a Spektrum logo
screen will show, then the
Main Screen will show on
the LCD screen (P).
2
3
FPO
2
4
P
P
1
