7. Communications
7.1 Infrared (IR)
All products in the range can communicate via an infrared link between adjacent controllers.
It enables the parameters of this product (OEM) to be passed to a product fitted with RS485
(USER).
USER products are fitted with a graphics display and OEM products either have LED’s, or
three digit displays.
This unit is always an IR slave – No set-up or adjustment is needed.
For further information on Infrared and RS485 communication, see User Installation and
Maintenance Instructions.
IMPORTANT:
Do not cover or obstruct the infrared beam between products.
See appendix for further details.
6.3.14 PF – Probe factor
Shows the calculated probe factor, which indicates the condition of the probe.
This function cannot be edited.
See Section 9, fault finding, for acceptable limits.
6.3.15 End
Press the
OK
button to enter run mode.
