10.5 Cable / wire and Connector data
Mains and signal connector
Rising clamp plug-in terminal blocks with screwed
Termination
connectors
Cable size 0.2 mm² (24 AWG) to 2.5 mm² (14 AWG)
Stripping length 5 - 6 mm
Note: Use only the connectors supplied by Spirax-Sarco Limited – Otherwise Safety and
Approvals may be compromised.
TDS probe cable / wire
Type High temperature
Shield type Screened
4 (CP10 and CP20 - For most applications the 1.25 m (4 ft)
Number of cores heat resistant cable will need to be extended using
a junction box)
Gauge 1 - 1.5 mm² (18 - 16 AWG)
100 m (9990 and 999.0 ranges)
Maximum length 30 m (99.90 range)
10 m (9.990 range)
Recommended type Prysmian (Pirelli) FP200, Delta Crompton Firetuf OHLS
Pt100 probe cable / wire
Type High temperature, twisted
Shield type Screened
Number of cores 3
Gauge 1 - 1.5 mm² (18 - 16 AWG)
Maximum length 100 m (328 ft)
Recommended type Various
4-20 mA output cable / wire
Type Twisted pair
Shield type Screened
Number of pairs 1
Gauge 0.23 - 1 mm² (24 - 18 AWG)
Maximum length 100 m
Recommended type Various
