43
Burner (bur) - Only available if PURGE time is greater than 0 seconds.
Ranges ON or OFF
Default ON
Filter (FLt) - Only available if PURGE time is = 0 seconds.
ON or OFF (TC = 64 or 8 seconds). Please note that the 8 second
Ranges filter, also includes a 5% (FSD) Jump out function for CCD systems.
TC = Time constant
Default ON (OFF if PURGE - DURATION >0)
Pulsed (PuL) – Valve / solenoid drive
Ranges
OFF - STANDARD (continuous)
ON - Pulsed - 10 seconds open, 20 seconds closed
Default OFF
Retransmit (rEt) 0 - 20 mA or 4 - 20 mA output
Ranges 0 or 4 mA
Default 4 mA
Temperature compensation (tC)
Ranges 100 - 250°C
Default 184°C (10 bar g)
Resolution (steps) 1°C
Probe factor (PF)
Ranges 0.01 to 1.00
Data registers
Register Parameters
2 (Identity)
Note: When the device is an IR slave and there is a temporary error in the
IR Master-Slave comms, an offset of +32768 is added to the identification
value of that particular slave stored in the master's database.
1 Process variable (PV) - TDS @ 25°C
2 Set Point (SP)
3 μS/cm or ppm (general data)
4 Alarm 1
5 Range index
6 Probe factor
7 Temperature compensation (°C of °F)
8 Purge time (seconds)
9 Clean duration (seconds)
The format of the register data is 16 bit integer, with the most significant byte transmitted first.
11. Appendix - Data registers
