Fig. 19
4.1 Advance to TUNE in the SP2 main menu.
Press key to advance to travel switch 1 (TS1).
Dead-band
(dBand)
ä
ä
Shut-off maximum
(S-MAX)
Characterisation
(LIN / FAST /
EQUAL)
Time to open
(T-UP)
Time to close
(T-dWN)
Travel switch 2
(TS2)
Normally closed
Travel switch 1
(TS1)
Normally open
ä
Shut-off minimum
(S-MIN)
TUNE
ä
ä
ä
ä
ä
ä
4. Programming and commissioning
travel switches
