Getting Started
Procedure 6: Install the Ferrite Block
Getting Started with Spirent TestCenter | 33
Figure 1-9. Ferrite Block Installation
2
Clamp the ferrite
block around the
Ethernet cable.
1
Place the Ethernet
cable in the opened
ferrite block.
3
Note:
In this example, the ferrite block is placed near the end
of the Ethernet cable that connects to the chassis.
