PARTS LIST
NO.
DESCRIPTION
Q'TY
1
Main Frame
1
2
Console Mast
1
3
Handle Bar
1
5
Rear Stabilizer
1
6
Seat Slider
1
7
Sliding Seat Mount
1
8
Fix Plate
1
9
Idler Wheel Assembly
1
11
Crank Axle
1
13
Chain Cover Bracket
1
14
Drive Belt
1
15
Drive Pulley
1
16L
Crank Arm(L)
1
16R
Crank Arm(R )
1
17
6004_Bearing
2
18
6203_Bearing
2
19
Seat
1
20
Generator/Brake
1
21
Generator/Brake Controller
1
22
Magnet
1
23
450m/m_Sensor W/Cable
1
24
Ø 31.8 × 5T × 255m/m_Handgrip Foam
2
25
Ø 31.8 × 5T × 215m/m_Handgrip Foam
2
26
850m/m_Handpulse W/Cable Assembly(XHP-3)
1
27
AC Input Module
1
28
850m/m_Handpulse W/Cable Assembly(XHP-4)
1
29
2200m/m_Computer Cable
1
30
200m/m_Wire Brake Coil Harness(Red)
1
31
550m/m_Generator Wire Harness
1
32
80m/m_Connecting Wire (White)
1
34
Console Assembly
1
34-01
Console Top Cover
1
34-02
Console Bottom Cover
1
34-03
Console Inner Cover
1
34-04
500m/m_Fan Assembly
1
34-05
Interface Board
1
34-06
Console Display Board
1
34-07
Main Key Board
1
34-08
W/Receiver, HR
1
34-09
Bluetooth
1
34-10
CASFE Board
1
34-11
USB charging module
1
