SPL Phonitor xe - Angle and Crossfeed Settings

14
Phonitor Matrix
In Detail
An analog filter design creates interaural time and level differences for four different speaker placements.
This analog filter design is controlled by the crossfeed and angle parameters.
Angle
With the ANGLE switch you adjust the interaural time
difference which is related to the placement of the
speakers.
22°22°
30°30°
40°40°
55°55°
