Output selection
Output selection
With the Output F/R switch () you send the headphone signal to the headhone connectors on
the front or on the rear side.
Set to the R setting, the headphone signal passes through to both the headhone connectors on
the rear side.
Please note that the standard headphone output () takes priority over the balanced headphone output ().
There is no signal at the balanced headphone output if a headphone is already plugged into the standard head-
phone output.
To protect the headphone power amplifier stage and guarantee a long and consistent performance please note:
• Turn down VOLUME before swapping headphones.
• Never insert a mono jack plug into the front panel stereo jack.
• Make sure that the headphones stereo jack is fully inserted.
• If you use an adapter from , mm to /" (, mm) on your headphone make sure that the adapter is fully
screwed on respectively fully plugged in.
