SPL Phonitor xe - Configuration Options; DIP Switches

27
DIP switches
DIP switches
With the DIP switches () on the bottom of the unit the following settings can be chosen:
Level increase of the headphone output
By using the DIP switch  you can increase the level of the headphone outputs to better feed power-hungry
headphones.
DIP switch : ON = The headphone output is boosted to + dB.
RCA input sensitivity
With DIP switch  you can change the sensitivity of RCA input.
DIP switch : ON = The analog RCA input sensitivity is changed from -dBV (HiFi level) to dBu (Studio level).
