SPL Phonitor xe - Matrix Adjustment and Operation

18
Phonitor Matrix
Adjustment of the Phonitor Matrix
By using the CROSSFEED switch () and the ANGLE switch () you can adjust the headphone playback through the
Phonitor xe to your room with your loudspeaker setup.
• Play some audio material you know well with the Phonitor xe and go to a place where you usually listen to
music through speakers.
• Set the ANGLE switch according to your loudspeaker placement (see page).
• Then set the CROSSFEED switch to the value that comes closest to your familiar loud-
speaker-listening sound.
Listen to the instruments panned in the stereo field. These instruments shall have the
same positions on headphones.
