Welcome
and thank you for choosing the Phonitorxe.
The Phonitor xe is the ultimate standalone device for headphone enthusiasts. It offers connections for head-
phones operated both balanced and unbalanced. With up to . W output power the Phonitor xe delivers an
impressive performance.
The Phonitor xe is the first Phonitor headphone amplifier which can be equipped with the brand-new SPL DAC.
This optional internal Uber-DAC qualifies the Phonitor xe to convert with outstanding sonic performance both PCM up
to  kHz sample rate and  bit as well as DSD up to DSD .
VOLTAiR technology is what we also call the SPL V Rail Technology within the Professional Fidelity series. This
makes the Phonitorxe an outstandig device in terms of dynamic range, signal-to-noise ratio and headroom deliver-
ing an exceptional sound experience with invincible serenity, transparancy and realness.
