Installation requirements 7
If you have... You’ll need...
no access to Hot/Cold
water hookups
Splendide Faucet Adapter
Kit, or equivalent.
concerns about the
appliance shifting in
your RV or boat
water damage
concerns
Splendide SecureFit bracket
kit, or equivalent.
Splendide Drain-A-Way Pan,
or equivalent.
Electrical
• Machine Voltage/Amperage - 120V, 60 Hz,
1300 W, 10.5 Amp.
• Connection - 3-prong plug with 6’ cord is
provided with the machine.
• Circuit/Protector - 3-wire single phase, 120V,
60 Hz, AC, on a separate 15 Amp circuit.
Location
• This machine may be installed free
standing as well as in a recessed area,
closet, or alcove
• Minimum Installation Spacing - 0” on
sides and 1” in front and back. NOTE:
Additional installation spacing needs to be
considered for easy installation, servicing,
and compliance with state and federal
codes.
• Floor - Must support at least 280 lbs. and
be a solid, level surface. DO NOT install on
carpet.
• RV/Marine Installations - When locating
the appliance in a towable trailer or
watercraft, position the machine over the
axles or mid-ship where movement is at a
minimum. Block the machine to prevent
extreme movement.
• NO DRYER VENT - This appliance uses an
internal water condenser to dry laundry.
All humidity stays within the unit and is
drained as water. NO heated or
conditioned air is exhausted outside; NO
exhaust vent is needed.
Drainage
Standpipe Diameter/Capacity - Needs a 1 ¼”
minimum diameter standpipe with a minimum
carry-away capacity of 7 gallons per minute.
Top of Standpipe - Must be between 25” and 34”
high from the bottom of the machine.
Outlet End of Drain Hose (provided with the unit)
- Must be at least 20” above the bottom of the
washer-dryer. An air break must be available at the
standpipe to avoid siphoning. No more than 6” of
the drain hose should be inserted into the drain
pipe to prevent siphoning.
