SPORTSTECH sTread Lite - Page 35

35
DE
EN
ASSEMBLY COMPONENTS
(C)
Left and Right
Handlebar Brackets x1
(B)
Computer Console x1
(A)
Base Frame x1
(D)
Left and Right
Handlebar Covers x1
(E)
Left and Right Base
Covers x1
(F)
Tablet Holder x1
Tablet Holder x1
Holder
Tablet Stand
End Cover
You assemble the tablet holder (F) by putting together the three individual components listed. The
ball joint of the holding arm must lock firmly into the joint shell on the back of the holder.
