Step 2 (Figure 28):
 maintaining in position the washer and the nut (C), insert the new electronic head;
 fix the nut (C) using key CH24;
 unscrew for seven turns the stop dowel (F) in order to enable the sensor mechanism;
 remove the top locking device A-C-D.
Figure 28: electronic head substitution – Step 2
Step 3:
 follow Step 3 (Figure 26) indicated in 6.3  Displacer Substitution to set the zero value.
F
C
