ASP 116 EVOLUTION – INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
15
Auto Tuning procedure
Mandatory step to get the lift move. Make this setting in Emergency or Temporary
operation. The auto-tuning of a gearless motor is very noisy but this is quite
normal.
Set “YES” to launch the auto-tuning
+
MOTOR’S MOVEMENT TEST
Go to chapter 7
Other possible combinations :
Choose « ACB » and « NO »
Choose « ACB » and « YES »
OR
Choose « ABC » and « YES »
OR
Restart from
AUTO TUNING
NO
AUTO TUNING
YES
STEP 1
PHASE ROTATION
ACB
STEP 4
STEP 1
REVERSE ROTATION
NO
PHASE ROTATION
AACB
REVERSE ROTATION
YES
PHASE ROTATION
AABC
REVERSE ROTATION
YES
PUSH ON
UP IN EMCY
AUTO TUNING
DONE
STEP 2
STEP 3
ENTER
