There are 2 kinds of landings boards:
- 137SP
- 228SP
These 2 boards manage calls and displays, and also the voice synthesizer for the 137SP.
137SP may also be used for the Pit Inspection Box in case this equiment is present on the
lift. If so, this board is also plugged on the Landing CAN bus, and its ID number must be set
up to #27 (see board encoding §15.7)
232SP (colour) or 235SP (blue) displays wiring
228SP BOARD 137SP BOARD
OU
Calls buttons wiring
228SP BOARD 137SP BOARD
