ASP 116 EVOLUTION – INSTALLATION MANUAL
Sprinte SAS. All rights reserved , including translations.
45
122SP,123SP and 124SP (dot matrix) displays wiring
228SP BOARD 137SP BOARD
Loud-speaker wiring
137SP BOARD
Firemen’s service key wiring
228SP BOARD 137SP BOARD
: Wiring on all floors except the lowest one.
: Wiring only for the lowest one.
CN5
CN5
HP
CN4
CN7
CN4
CN7
