Boards encoding (binary coding)
Every dip-switch set to ON position gets a binary value:
#Dip-switch set to « ON » 1 2 3 4 5 6 7 8
Matching value 1 2 4 8 16 32 64 128
e.g. for encoding board#14, set the following dip switches : #1, 3 & 4 => 1 + 4 + 8 = 13. (for board#1, all dip-switches
are set to off, corresponding to 0 value).
Each board must have a unique number
Boards programming’s procedure
Once every board has been configured and connected , you can run the programming ‘s procedure:
Only the outdated boards will be reprogrammed
+
+ …
+ for 4 sec.
The controller restarts and indicates the number of board which is reprogrammed.
Please wait until the end of the procedure.
