2. Manual reprogramming :
The manual reprogramming erases the program AND all the current parameters of your
controller.Then it reloads the program and the parameters from those located on the
SDcard.
This manual reprogramming allows to change the software whatever the version is.
Use a SDcard which must contain at least all the following files :
The DCF.TXT file is mandatory on the SDcard, it contains all the parameters that
will be used by the controller.
Shut down the power supply of the controller and unplug the battery (connector AR1-A /
214SP).
Engage the Emergency Operation, or unplug the connector AR1M/ 216SP.
Press and keep the « ENTER » key down.
Switch on power supply and replug the battery.
The reprogramming process is launched as soon as you see on the screen :
you can now release the « ENTER » key.
After few minutes , the controller is operational with the software and the parameters from the
SDcard.
