SRAM G2 RS User Manual

25
Piston Assembly Removal
Piston Assembly Removal
Push the SwingLink pivot pin out of the lever body.Push the SwingLink pivot pin out of the lever body.
Remove the SwingLink.Remove the SwingLink.
Remove the SwingLink bushings.Remove the SwingLink bushings.
Use long-tipped internal snap ring pliers to apply downward pressure Use long-tipped internal snap ring pliers to apply downward pressure
to the lever body and remove the snap ring.to the lever body and remove the snap ring.
Turn the lever body upside down to allow the washer to fall out of the Turn the lever body upside down to allow the washer to fall out of the
body.body.
⚠ CAUTION - EYE HAZARD
Wear safety glasses. Do not look directly into the lever body while
performing this step. The internal piston/spring assembly is preloaded
and will come out of the lever body quickly, which can result in injury.
1
3 mm
2
RS
3
4 mm
4
internal snap ring pliers
