SRAM G2 RS User Manual

29
RS Lever Blade Installation
Hold the spring and main pivot clip in place while installing the lever Hold the spring and main pivot clip in place while installing the lever
blade. Insert the reach adjust screw pin into the cam hole.blade. Insert the reach adjust screw pin into the cam hole.
Line up the cam and lever blade with the holes in the lever body, then Line up the cam and lever blade with the holes in the lever body, then
press the pivot pin through the holes.press the pivot pin through the holes.
Use a hammer to gently tap the pivot pin into the pivot hole.Use a hammer to gently tap the pivot pin into the pivot hole.
Make sure the lever bias spring is seated properly in the lever. The Make sure the lever bias spring is seated properly in the lever. The
outboard end of the spring must press against the lever blade, while outboard end of the spring must press against the lever blade, while
the inboard end of the spring must press against the lever body. If the the inboard end of the spring must press against the lever body. If the
return spring is not seated properly, you will not be able to adjust the return spring is not seated properly, you will not be able to adjust the
reach of the lever blade.reach of the lever blade.
4
5
Hammer

SRAM G2 RS Specifications

General

Brake Type	Hydraulic Disc
Lever Material	Aluminum
Caliper Design	2-Piston
Brake Pad Type	Organic
Reach Adjust	Yes
Rotor Size Compatibility	140mm, 160mm, 180mm, 200mm
