10Lever Blade Removal
Use a T10 TORX® wrench to remove the reservoir cap bolts from
the reservoir cap.
Remove the reservoir cover and bladder from the lever body.
Pour the fluid from the brake lever body into a pan.
Separate the bladder from the reservoir cover.
Spray isopropyl alcohol on the bladder and the reservoir cover and
clean them with a rag.
NOTICE
All components must be completely dry before reinstalling them.
Moisture residue from cleaning the bladder can leak out of the
bladder as it dries, which can be misinterpreted as a system leak
when it is not.
5
T10 TORX wrench 15 N•m (133 in-lb) 22 mm
6
7 7
8
