16Lever Blade Installation
RS only: Apply a small amount of Loctite® Threadlocker Blue 242®
onto the threads of the SwingLink™ pivot pinch bolt.
Use a T8 TORX® wrench to thread the SwingLink pivot pinch bolt
into the SwingLink.
5
Loctite® Threadlocker Blue 242® 20 mm or 15 mm Thru Axle
T8 TORX wrench QR
