17Lever Blade Installation
DB5 and R only: Use your hand to insert the lever assembly into
the lever body, placing the push rod into the piston and lever
return spring on the lever body.
Make sure your lever return spring is seated in the lever properly,
as seen in the picture. The reach adjuster must be seated in the
cam hole, if it is not set properly you will be unable to adjust your
reach.
RS only: Use your hand to insert the lever assembly into the lever
body, placing the push rod into the piston and lever return spring
on the lever body.
Make sure your lever return spring is seated in the lever properly,
as seen in the picture. The end of the spring that points outward
must be placed against the lever blade, while the end of the spring
that points inward rests against the lever body.The reach adjuster
must be seated in the cam hole, if it is not set properly you will be
unable to adjust your reach.
6
