32R Lever Blade Installation
Use a torque wrench with a T10 TORX® bit socket to tighten each
reservoir cap bolt to 1.1-1.3 N·m (9-12 in-lb).
Cut the hose to install a new barb and compression fitting.
NOTICE
You must install a new hose barb and compression fitting before
reconnecting the brake lever to the hose.
Apply DOT grease to the hose barb threads. Thread the hose barb into
the hose until it is flush with the end of the hose.
NOTICE
Do not overtighten the hose barb. Overtightening may cause damage
to the hose liner.
Install the compression nut onto the hose.
9
T10 TORX 1.1-1.3 N•m (10-12 in-lb) T10 TORX®
SRAM® Hydraulic Hose Cutter
10
11
12
