SRAM Guide RS User Manual

10Caliper Piston Removal
Remove the Guide™ pad spreader.
Remove the pad retention bolt.
Remove each caliper body bolt.
Separate the caliper body halves.
Set the heat shield aside.
Remove the caliper o-ring from the outboard side of the caliper.
4
2.5 mm hex wrench QR
5
T25 TORX wrench Rubber-tipped blow gun chuck nozzle 22 mm
6
7

SRAM Guide RS Specifications

General

Brake Type	Hydraulic Disc
Lever Material	Aluminum
Caliper Design	2-Piston
Adjustment	Reach Adjust
Fluid Type	DOT 5.1
Pad Material	Organic
Caliper Material	Aluminum
Rotor Compatibility	CenterLine
Rotor Size	160mm, 180mm, 200mm
Weight	375g (Direct Mount, 800mm hose)
