SRAM Guide RS User Manual

11Caliper Piston Removal
Remove the pistons from each caliper body half.
Remove the piston seals from each caliper body half. Install new seals
inside each caliper body half.
⚠ WARNING
Do not scratch the seal gland with the pick. Scratches could cause fluid
to leak when the brake is applied, which will contaminate the brake
pads and could lead to a brake failure.
8
9
Pick 20 mm or 15 mm Thru Axle

SRAM Guide RS Specifications

General

Brake Type	Hydraulic Disc
Lever Material	Aluminum
Caliper Design	2-Piston
Adjustment	Reach Adjust
Fluid Type	DOT 5.1
Pad Material	Organic
Caliper Material	Aluminum
Rotor Compatibility	CenterLine
Rotor Size	160mm, 180mm, 200mm
Weight	375g (Direct Mount, 800mm hose)
