27R Lever Blade Installation

R Lever Blade Installation

Insert the lever blade bushings into both sides of the lever.

Steps to reassemble the R lever blade assembly:

Place the washer on the cam/push rod assembly. You may add a dab

of SRAM® DOT grease to hold the washer in place.

Install the lever return spring onto the cam/push rod assembly.

While holding the cam/push rod/lever return spring/washer in place,

install the assembly onto the lever blade and proceed to step 2.
