SRAM Guide RS User Manual

30R Lever Blade Installation
Use a torque wrench with a T10 TORX® bit socket to tighten each
reservoir cap bolt to 1-1.3 N·m (9-11 in-lb).
Apply SRAM® DOT grease onto the compression nut and install the
compression fitting and nut into the lever.
Use a flare nut crowfoot with a torque wrench to tighten the
compression nut to 8 Nm (71 in-lb).
Spray isopropyl alcohol on the lever body and clean it with a rag.
NOTICE
You must bleed the brakes to complete the service.
For brake bleed, brake hose shortening, and brake pad replacement instructions, visit www.sram.com/service.
9
T10 TORX® 1-1.3 N•m (9-11 in-lb) T10 TORX®
10
11
8 mm flare nut crowfoot 8 Nm (71 in-lb) 22 mm

SRAM Guide RS Specifications

General

Brake Type	Hydraulic Disc
Lever Material	Aluminum
Caliper Design	2-Piston
Adjustment	Reach Adjust
Fluid Type	DOT 5.1
Pad Material	Organic
Caliper Material	Aluminum
Rotor Compatibility	CenterLine
Rotor Size	160mm, 180mm, 200mm
Weight	375g (Direct Mount, 800mm hose)
