29R Lever Blade Installation

Use a torque wrench and a T8 TORX wrench to tighten the bolt to

2.7-3.2 N·m (24-28 in-lb).

Use a T8 TORX wrench to install a new binder bolt plug.

Press the bladder into the reservoir cap so that the bladder is properly

seated and ﬂush with the reservoir cap.

Insert the reservoir cap and bladder assembly onto the lever body.

T8 TORX 2.7-3.2 N•m (24-28 in-lb) 22 mm

T8 TORX wrench 2.7-3.2 N•m (24-28 in-lb) 22 mm

7 7
