SRAM Guide Ultimate Service Manual

17Lever Blade Removal
Use a T10 TORX
®
wrench to remove the reservoir cap bolt nearest to
the lever blade.
Carefully turn the lever body upside down so that the detent spring
and ball fall out of the lever body. If they do not initially fall out, gently
tap the lever against a clean shop towel.
Use a T10 TORX
®
wrench to remove the other reservoir cap bolt.
Remove the reservoir cover and bladder from the lever body.
5
T10 TORX wrench 15 N•m (133 in-lb) 22 mm
6
7
T10 TORX wrench 15 N•m (133 in-lb) 22 mm
8

SRAM Guide Ultimate Specifications

General

Brake Type	Hydraulic Disc
Caliper Design	4-Piston
Caliper Material	Aluminum
Compatibility	MatchMaker X
Rotor Compatibility	CenterLock, 6-Bolt
Adjustment	Reach Adjust
Intended Use	Trail, Enduro
Pad Material	Organic
Weight	360g
