34Lever Blade Installation
Press the bladder into the reservoir cap. The bladder must be flush with
the edge of the cap to be properly installed.
Place the reservoir cap/bladder assembly onto the lever body.
Use a torque wrench and a T10 TORX
®
bit socket to tighten each
reservoir cap bolt to 1.1-1.3 N·m (10-12 in-lb).
Spray isopropyl alcohol on the lever body and clean it with a
shop towel.
6 6
7
8
T10 TORX bit 1.1-1.3 N•m (10-12 in-lb) 22 mm
9
