SRAM Rockshox SID SL - Exploded View - Sid Sl Select + \ Charger 2 Damper Rl

11
Exploded View - SID SL Select + \ Charger 2 Damper RL
Exploded View - SID SL Select + \ Charger 2 Damper RL
Top cap
Air shaft
Top out bumper cone
Air valve cap
Air piston
Crush washer
Bottom bolt
Rebound adjuster
Rebound nut
Crush washer
Rebound damper shaft
Compression damper
Top cap
Bottomless Token(s)
Upper tube
Brake hose guide
Lockout adjuster knob
and retaining screw
Lower leg
Seal head
Jounce
bottom out
bumper
Retaining ring
Wiper seal
Foam ring
Coupler
Cartridge
tube
Seal head
Dig Valve
Bottom cup
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Cable stop collar
Spool
Glide ring
Retention screw
SID SL Select + RL R
