Exploded View - SID SL Ultimate \ Charger Race Day Damper
Exploded View - SID SL Ultimate \ Charger Race Day Damper
Top cap
Air shaft
Top out bumper cone
Air piston
Crush washer
Bottom bolt
Rebound adjuster
Rebound nut
Crush washer
Rebound damper shaft
Compression damper
Top cap
Bottomless Token(s)
Upper tube
Brake hose guide
Lockout adjuster knob
and retaining screw
Lower leg
Seal head
Jounce
bottom out
bumper
Retaining ring
Wiper seal
Foam ring
Bottom cup
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Cable
stop collar
and screw
Spool and screw
SID SL Ultimate R
Air valve cap
